FiberTechnic PLC Fiber Optic Splitter 1:8 LC/APC, G.657A, 1.5m, Steel Box

Symmetrical PLC splitter with 1:8 optical power split in 0.9mm pigtail sheath in steel box housing with LC/APC connectors.

FiberTechnic PLC (Planar Wave Circuit) Splitters with LC/APC connectors are used to split the optical power transmitted in the optical line. Splitters in steel box housing are supplied with ready connectors to be plugged into LC/APC fibre optic adapters on the panel of cabinets, patch panels or fibre optic boxes. Design: Planar technology, allows a splitter to be manufactured with a signal division of up to 128, while guaranteeing the small size of the product itself and very high stability of operation over the full bandwidth from 1260-1620nm.

Splitter packed in a blister pack of 1pc.

Application:

• FTTx networks,
• PON networks,
• LAN, MAN, WAN networks,
• CATV cable networks
• Testing of equipment in PON applications
